Brückenschaltung 1. Schaltung 1 R3 = 40 Ohm R4 = 20 Ohm U3 = 40V U4 = 20 V.

Ähnliche Präsentationen


Präsentation zum Thema: "Brückenschaltung 1. Schaltung 1 R3 = 40 Ohm R4 = 20 Ohm U3 = 40V U4 = 20 V."—  Präsentation transkript:

1 Brückenschaltung 1

2 Schaltung 1 R3 = 40 Ohm R4 = 20 Ohm U3 = 40V U4 = 20 V

3 Schaltung 1 2 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

4 U3 = 40V U4 = 20 V Schaltung 1 2 = +20V R1 = 80 Ohm R2 = 40 Ohm R3 = 40 Ohm R4 = 20 Ohm U3 = 40V U4 = 20 V

5 Schaltung 1 2 = +20V U1 = ?? U2 = ?? R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

6 Schaltung 1 2 = +20V U1 = 40V U2 = ?? R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

7 Schaltung 1 2 = +20V U1= 40V U2 = 20 V R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

8 Schaltung 1 2 = +20V U1 = 40V U2 = 20 V R1 = 80 Ohm R2 = 40 Ohm 1 = ??? U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

9 Schaltung 1 2 = +20V U1 = 40V U2 = 20 V R1 = 80 Ohm R2 = 40 Ohm 1 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

10 Schaltung 1 2 = +20V U1 = 40V U2 = 20 V R1 = 80 Ohm R2 = 40 Ohm 1 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = ???

11 Schaltung 1 2 = +20V U1 = 40V U2 = 20 V R1 = 80 Ohm R2 = 40 Ohm 1 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = 0V

12 Schaltung 1 2 = +20V U1 = 40V U2 = 20 V R1 = 80 Ohm R2 = 40 Ohm 1 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = 0V Die Spannung an der Brücken- diagonale beträgt OV -> Die Brücke ist ABGEGLICHEN

13 Brückenschaltung 2

14 Schaltung 2 2 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

15 Schaltung 2 2 = +20V R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

16 Schaltung 2 2 = +20V U1 = ??? U2 = ??? R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

17 Schaltung 2 2 = +20V U1 = 30V U2 = 30 V R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

18 Schaltung 2 2 = +20V U1 = 30V U2 = 30 V R1 = 40 Ohm R2 = 40 Ohm 1 =??? U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

19 Schaltung 2 2 = +20V U1 = 30V U2 = 30 V R1 = 40 Ohm R2 = 40 Ohm 1 = +30V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

20 Schaltung 2 2 = +20V U1 = 30V U2 = 30 V R1 = 40 Ohm R2 = 40 Ohm 1 = +30V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = ???

21 Schaltung 2 2 = +20V U1 = 30V U2 = 30 V R1 = 40 Ohm R2 = 40 Ohm 1 = +30V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = +10V

22 Brückenschaltung 3

23 Schaltung 3 2 = +20V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

24 Schaltung 3 2 = +20V R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

25 Schaltung 3 2 = +20V U1 = ??? U2 = ??? R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

26 Schaltung 3 2 = +20V U1 = 50V U2 = 10 V R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

27 Schaltung 3 2 = +20V U1 = 50V U2 = 10 V R1 = 50 Ohm R2 = 10 Ohm 1 =??? U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

28 Schaltung 3 2 = +20V U1 = 50V U2 = 10 V R1 = 50 Ohm R2 = 10 Ohm 1 = +10V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

29 Schaltung 3 2 = +20V U1 = 50V U2 = 10 V R1 = 50 Ohm R2 = 10 Ohm 1 = +10V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = ???

30 Schaltung 3 2 = +20V U1 = 50V U2 = 10 V R1 = 50 Ohm R2 = 10 Ohm 1 = +10V U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm U 12 = -10V

31 ENDE
