1 Andriy Terletskyy Lead Database Architect Hamburg, 17.06.2010
Geschäftslogik in der Datenbank Architektur und Objektorientierte PL/SQL-Programmierung Andriy Terletskyy Lead Database Architect Hamburg,

2 Geschäftslogik Geschäftslogik (engl. Business Logic, auch Anwendungslogik) ist ein abstrakter Begriff in der Softwaretechnik, der eine Abgrenzung der durch die Aufgabenstellung selbst motivierten Logik eines Softwaresystems von der technischen Implementierung zum Ziel hat. Allerdings ist der Begriff unscharf, da eine klare Trennung oft nicht möglich ist. Mehrfache BL-Umsetzung Datenbank Abhängigkeit Datenverarbeitungs- und Datenerfassungslogik Oracle EE ist mehr als eine Datenbank (Speicherort) SQL und PL/SQL Engine DBMS-Packages Object Types Type Mapping (Java&.NET) JPublisher, SQLData, STRUCT, ODP.NET

3 Datenbanken Architektur

4 Virtuelle ODBMS auf Basis RDBMS (DOAG Konferenz 2004)
Aufbau OO-ROWTYPE (ROWTYPE + DML, DEFAULT, TO_STRING, DBMS_OUTPUT- Methoden, PK/UK- Konstruktoren, ROW_LOCK) BO-Typen (Vererbung, Aggregation, Assoziation) Verwendung Methoden statt üblicher DML- Anweisungen Datennormalisierung über RDBMS PK/UK- Konstruktoren - ziehen referenziertes Objekt über relationale ID (DEREF- Analogon) Generator Java-Class PL/SQL-Wrapper DDL-Trigger mit asynchroner Queue

5 Tabelle und OO-Rowtype (Beispiel)
CREATE OR REPLACE TYPE ROW_STATUS UNDER GLOBAL.TYPE_OBJECT (  -- attributes     STATUS_ID          NUMBER(12)   , KURZBEZEICHNUNG    VARCHAR2(50)   , ERSTELLT_ZST       DATE   , ERSTELLT_ID        VARCHAR2(30)   , GEAENDERT_ZST      DATE   , GEAENDERT_ID       NUMBER(12)   , GEAENDERT_ZAEHLER  NUMBER(10)   , BEZEICHNUNG        VARCHAR2(200) -- constructors   , CONSTRUCTOR FUNCTION ROW_STATUS RETURN SELF AS RESULT   , CONSTRUCTOR FUNCTION ROW_STATUS(IN_STATUS_ID NUMBER) RETURN SELF AS RESULT   -- member functions   , MEMBER FUNCTION ROW_EXISTS(IN_STATUS_ID NUMBER) RETURN BOOLEAN   , OVERRIDING MEMBER FUNCTION compare(in_type1 GLOBAL.TYPE_OBJECT ,in_type2 GLOBAL.TYPE_OBJECT) RETURN INTEGER   -- member procedures   , MEMBER PROCEDURE ROW_INSERT   , MEMBER PROCEDURE ROW_UPDATE   , MEMBER PROCEDURE ROW_MERGE   , MEMBER PROCEDURE ROW_SAVE   , MEMBER PROCEDURE ROW_DELETE   , MEMBER PROCEDURE ROW_SELECT(IN_STATUS_ID NUMBER)   , MEMBER PROCEDURE ROW_DEFAULT   , MEMBER PROCEDURE ROW_LOCK   , MEMBER PROCEDURE ROW_LOCK(IN_STATUS_ID NUMBER) ) NOT FINAL CREATE OR REPLACE TRIGGER TBI$STATUS BEFORE INSERT ON WPH.STATUS FOR EACH ROW WHEN ( NEW.STATUS_ID IS NULL) DECLARE BEGIN SELECT STATUS_SEQ.NEXTVAL INTO :NEW.STATUS_ID FROM DUAL; END; CREATE OR REPLACE TRIGGER TBU$STATUS BEFORE UPDATE ON WPH.STATUS FOR EACH ROW :new.Geaendert_ID := SYS_CONTEXT('VPD', 'USERID'); :new.Geaendert_ZST := sysdate; :new.Geaendert_Zaehler := :old.Geaendert_Zaehler + 1; end;

6 RETURNING clause (INSERT und UPDATE)
  MEMBER PROCEDURE ROW_INSERT   IS     methodenname  CONSTANT VARCHAR2(100) := 'WPH.ROW_STATUS.ROW_INSERT';   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, 'Parameters: ');     END IF;     INSERT INTO WPH.STATUS ( STATUS_ID                             ,KURZBEZEICHNUNG                             ,BEZEICHNUNG                   ) VALUES ( SELF.STATUS_ID                             ,SELF.KURZBEZEICHNUNG                             ,SELF.BEZEICHNUNG                  ) RETURNING                              STATUS_ID                             ,KURZBEZEICHNUNG                             ,ERSTELLT_ZST                             ,ERSTELLT_ID                             ,GEAENDERT_ZST                             ,GEAENDERT_ID                             ,GEAENDERT_ZAEHLER                             ,BEZEICHNUNG                   INTO                              SELF.STATUS_ID                             ,SELF.KURZBEZEICHNUNG                             ,SELF.ERSTELLT_ZST                             ,SELF.ERSTELLT_ID                             ,SELF.GEAENDERT_ZST                             ,SELF.GEAENDERT_ID                             ,SELF.GEAENDERT_ZAEHLER                             ,SELF.BEZEICHNUNG                            ;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||SELF.TO_STRING()                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;

7 SAVE und MERGE   MEMBER PROCEDURE ROW_SAVE   IS     methodenname  CONSTANT VARCHAR2(100) := 'WPH.ROW_STATUS.ROW_SAVE';   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, 'Parameters: ');     END IF;     IF ROW_EXISTS(IN_STATUS_ID => SELF.STATUS_ID) THEN       SELF.ROW_UPDATE;     ELSE       SELF.ROW_INSERT;     END IF;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||SELF.TO_STRING()                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;     MEMBER PROCEDURE ROW_MERGE   IS     methodenname  CONSTANT VARCHAR2(100) := 'WPH.ROW_STATUS.ROW_MERGE';   BEGIN     MERGE INTO WPH.STATUS A     USING ( SELECT SELF.STATUS_ID     AS STATUS_ID                   ,SELF.KURZBEZEICHNUNG   AS KURZBEZEICHNUNG                   ,SELF.BEZEICHNUNG       AS BEZEICHNUNG             FROM DUAL ) B     ON (A.STATUS_ID         = B.STATUS_ID)     WHEN MATCHED THEN UPDATE SET   KURZBEZEICHNUNG   = B.KURZBEZEICHNUNG                                    ,BEZEICHNUNG       = B.BEZEICHNUNG     WHEN NOT MATCHED THEN INSERT ( STATUS_ID                                   ,KURZBEZEICHNUNG                                   ,BEZEICHNUNG                         ) VALUES ( B.STATUS_ID                                   ,B.KURZBEZEICHNUNG                                   ,B.BEZEICHNUNG                                 );   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||SELF.TO_STRING()                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;

8 Pessimistisches Locking - Default
  MEMBER PROCEDURE ROW_LOCK   IS     methodenname  CONSTANT VARCHAR2(100) := 'WPH.ROW_STATUS.ROW_LOCK';     v_lock                 NUMBER;   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, 'Parameters: ');     END IF;     SELECT GEAENDERT_ZAEHLER       INTO v_lock     FROM WPH.STATUS     WHERE STATUS_ID         = SELF.STATUS_ID     FOR UPDATE     ;     IF SELF.GEAENDERT_ZAEHLER <> v_lock THEN       SELF.ROW_SELECT(    IN_STATUS_ID         => SELF.STATUS_ID);     END IF;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||SELF.TO_STRING()                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END; declare i ROW_STATUS; begin i := ROW_STATUS(IN_STATUS_ID => 200); ... i.ROW_LOCK(); end;

9 Pessimistisches Locking mit PK oder UK
  MEMBER PROCEDURE ROW_LOCK(IN_STATUS_ID NUMBER)   IS     methodenname  CONSTANT VARCHAR2(300) := 'WPH.ROW_STATUS.ROW_LOCK(IN_STATUS_ID NUMBER)';   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, 'Parameters: '                             ||'IN_STATUS_ID = '||IN_STATUS_ID||';'                           );     END IF;     SELECT STATUS_ID           ,KURZBEZEICHNUNG           ,ERSTELLT_ZST           ,ERSTELLT_ID           ,GEAENDERT_ZST           ,GEAENDERT_ID           ,GEAENDERT_ZAEHLER           ,BEZEICHNUNG       INTO SELF.STATUS_ID           ,SELF.KURZBEZEICHNUNG           ,SELF.ERSTELLT_ZST           ,SELF.ERSTELLT_ID           ,SELF.GEAENDERT_ZST           ,SELF.GEAENDERT_ID           ,SELF.GEAENDERT_ZAEHLER           ,SELF.BEZEICHNUNG     FROM WPH.STATUS     WHERE STATUS_ID = IN_STATUS_ID     FOR UPDATE     ;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||'IN_STATUS_ID = '||IN_STATUS_ID||';'                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END; declare i ROW_STATUS; begin i := ROW_STATUS(); i.ROW_LOCK(IN_STATUS_ID => 200); end;

10 Optimistisches Locking - UPDATE
  MEMBER PROCEDURE ROW_UPDATE   IS     methodenname  CONSTANT VARCHAR2(100) := 'WPH.ROW_STATUS.ROW_UPDATE';   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, 'Parameters: ');     END IF;     UPDATE WPH.STATUS     SET KURZBEZEICHNUNG   = SELF.KURZBEZEICHNUNG        ,BEZEICHNUNG       = SELF.BEZEICHNUNG     WHERE STATUS_ID         = SELF.STATUS_ID       AND GEAENDERT_ZAEHLER = SELF.GEAENDERT_ZAEHLER     RETURNING STATUS_ID              ,KURZBEZEICHNUNG              ,ERSTELLT_ZST              ,ERSTELLT_ID              ,GEAENDERT_ZST              ,GEAENDERT_ID              ,GEAENDERT_ZAEHLER              ,BEZEICHNUNG          INTO SELF.STATUS_ID              ,SELF.KURZBEZEICHNUNG              ,SELF.ERSTELLT_ZST              ,SELF.ERSTELLT_ID              ,SELF.GEAENDERT_ZST              ,SELF.GEAENDERT_ID              ,SELF.GEAENDERT_ZAEHLER              ,SELF.BEZEICHNUNG     ;     IF SQL%ROWCOUNT <> 1 THEN       GLOBAL.RAISE(-20999); Der Datensatz hat sich zwischenzeitlich geändert     END IF;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||SELF.TO_STRING()                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;

11 Optimistisches Locking - DELETE
  MEMBER PROCEDURE ROW_DELETE   IS     methodenname  CONSTANT VARCHAR2(100) := 'WPH.ROW_STATUS.ROW_DELELE';   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, 'Parameters: ');     END IF;     DELETE FROM WPH.STATUS     WHERE STATUS_ID         = SELF.STATUS_ID       AND GEAENDERT_ZAEHLER = SELF.GEAENDERT_ZAEHLER;     IF SQL%ROWCOUNT <> 1 THEN       GLOBAL.RAISE(-20999); Der Datensatz hat sich zwischenzeitlich geändert     END IF;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_ERROR, methodenname, ' - Exception raised. '                             ||SELF.TO_STRING()                             ||', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;

12 Variablen und OO-ROWTYPE
declare s VARCHAR2(50); begin SELECT s.kurzbezeichnung INTO s FROM WPH.STATUS s WHERE s.sTATUS_ID=200; end; declare s WPH.STATUS.KURZBEZEICHNUNG%TYPE; begin SELECT s.kurzbezeichnung INTO s FROM WPH.STATUS s WHERE s.STATUS_ID=200; end; declare   s WPH.STATUS%ROWTYPE; begin   SELECT *   INTO s   FROM WPH.STATUS s   WHERE s.sTATUS_ID=200; end; declare s WPH.ROW_STATUS; begin s := WPH.ROW_STATUS(IN_STATUS_ID => 200); end;

13 Arbeiten mit OO-ROWTYPE
declare i ROW_STATUS; begin i := ROW_STATUS(IN_STATUS_ID => 200); i.DBMS_OUTPUT; i.KURZBEZEICHNUNG := 'Eingestellt'; i.ROW_UPDATE; end; <ROW_STATUS> <OBJECT_TYPE_NAME>WPH.ROW_STATUS</OBJECT_TYPE_NAME> <STATUS_ID>200</STATUS_ID> <KURZBEZEICHNUNG>Einstellung</KURZBEZEICHNUNG> <ERSTELLT_ZST> </ERSTELLT_ZST> <ERSTELLT_ID>-2</ERSTELLT_ID> <GEAENDERT_ZST> </GEAENDERT_ZST> <GEAENDERT_ID>1469</GEAENDERT_ID> <GEAENDERT_ZAEHLER>2</GEAENDERT_ZAEHLER> <BEZEICHNUNG>ORDERAUSFUEHRUNG-STATUS</BEZEICHNUNG> </ROW_STATUS> <KURZBEZEICHNUNG>Eingestellt</KURZBEZEICHNUNG> <GEAENDERT_ZST> </GEAENDERT_ZST> <GEAENDERT_ID>907</GEAENDERT_ID> <GEAENDERT_ZAEHLER>3</GEAENDERT_ZAEHLER>

14 Gattungsstamm – Input Daten
G       DE000AAR0082AAR "GD090  "GD100  01"GD100A 1"GD160  004"GD161  DE"GD170  EO "GD171  EUR"GD172  EUR"GD190  PD"GD195  227"GD196  1"GD198A SEC"GD198B 2000"GD198C 2003"GD198D ZZZZ"GD198E ZZZZ"GD198F E302"GD198G M401"GD200  00025"GD201  DE03472          "GD205B KA05"GD211  1"GD212  703"GD213  25"GD214  22"GD215A J"GD217  AAC"GD218  J"GD218A J"GD218B J"GD218C J"GD220  142"GD220A 004"GD220C 183"GD225  A"GD226  60"GD227  1"GD228  0413"GD230  MTH"GD234  1"GD240  "GD260  AAREAL BANK MTN.HPF.S.67 "GD270A Aareal Bank AG                "GD270B MTN-HPF.S.67 v.2010(2013)     "GD280A Serie 67 v (2013)       "GD290  "GD290A "GD300  "GD312  6"GD321  10"GD322  "GD323  "GD388A "GD388PIDE "GD400  03"GD410  9"GD420  7"GD423  J"GD424  B"GD430  099"GD440  2"GD455A "GD455E 1"GD473  ²NOM=1000,W=EUR;                         "GD481A 05"GD483  1"GD500  84"GD504A J"GD505B "GD505E 2"GD507  "GD545  1"GD545A 2"GD546  "GD571  J"GD572  J"GD621  099"GD622  DE000AAR0082"GD622PWAAR008"GD630A "GD630B EUR"GD650A "GD660  "GD663A N"GD663D N"GD669  "GD670A EUR"GD670B %"GD672  1"GD685  DTFSFB"GD697  2B"GD776  3"GD801A "GD805  F"GD810  093"GD811  1"GD812  16"GD812A 16"GD813  SEPT"GD813A SEPT"GD815  0092"GD815A "GD819  2"GD821B 09"GD822  01"GD841  2"GD861A "GD862  "GD910  "GD924  N"GD970G 01"GD986  ²deutsches Recht G       DE000AAR0082AAR "GV992  ²0660/J/ / / / / / / / / / / / /         ²0348/J/ / / / / / / / / / / / /         ²2597/J/ / / / / / / / / / / / / G       DE000AAR0082AAR "GV995  ²0660/ / / / / / / / / /J/ / / /         ²0348/ / / / / / / / / / /J/ / /         ²2597/ / / / / / / / / / /J/ / / E       NO "ED001  2"ED002A 1"ED004A DD"ED023  1"ED024A "ED025A "ED190  02 G       NO "GD090  "GD260  PETROLIA DRILLING    NK 5"GD270A Petrolia Drilling ASA         "GD270B Navne-Aksjer NK 5             "GD460A H       NO "HD008  "HD015  U       NO "UD001  1"UD002A 1"UD005  1"UD006  1"UD007  4"UD008A AZ"UD010A ST "UD010C "UD010D "UD011A ST "UD011C "UD011D "UD021  "UD021PINO "UD025  ²ca.                                     "UD034  "UD078  20"UD087  049"UD190  02"UD460A "UD460B

15 Gattungsstamm – Datenbank Model

16 Schwergewichtiger TYPE
CREATE OR REPLACE TYPE TYPE_GATTUNG AUTHID CURRENT_USER UNDER GLOBAL.TYPE_OBJECT (  -- Attributes   id               NUMBER(12) , isin             CHAR(12) , wkn              CHAR(6) , sh               NUMBER(2) , geloescht        DATE , name             VARCHAR2(80) , instrument       VARCHAR2(80) , fids             WP.TABLE_WMFID , ertraege         WP.TABLE_ERTRAG , kapitals         WP.TABLE_KAPITAL , ohc              WP.TABLE_GATTUNG_OHC , hauptversammlung WP.TABLE_HAUPTVERSAMMLUNG , bogenerneuerung  WP.TABLE_BOGENERNEUERUNG , umtausch         WP.TABLE_UMTAUSCH , verlosung        WP.TABLE_VERLOSUNG , termin           WP.TABLE_GATTUNG_TERMIN , opposition       WP.TABLE_OPPOSITION , ifp              WP.TABLE_WMFID , NWKN             VARCHAR2(4000) -- Nationale WKN   -- Methods , CONSTRUCTOR FUNCTION TYPE_GATTUNG RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(in_id NUMBER) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(IN_ID NUMBER, IN_DATUM DATE) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(in_isin VARCHAR2, in_sh NUMBER DEFAULT 0) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(in_wkn VARCHAR2, in_sh NUMBER DEFAULT 0) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(in_wkn VARCHAR2, in_sh NUMBER, in_datum DATE) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(in_isin VARCHAR2, in_wkn VARCHAR2, in_sh NUMBER DEFAULT 0, in_geloescht DATE DEFAULT NULL) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION TYPE_GATTUNG(in_isin VARCHAR2, in_wkn VARCHAR2, in_instrument VARCHAR2) RETURN SELF AS RESULT , MEMBER PROCEDURE add_ertrag(in_ertrag WP.TYPE_ERTRAG) , MEMBER PROCEDURE add_hauptversammlung(in_hauptversammlung WP.TYPE_HAUPTVERSAMMLUNG) , MEMBER PROCEDURE add_bogenerneuerung(in_bogenerneuerung WP.TYPE_BOGENERNEUERUNG) , MEMBER PROCEDURE add_kapital(in_kapital WP.TYPE_KAPITAL) , MEMBER PROCEDURE add_umtausch(in_umtausch WP.TYPE_UMTAUSCH) , MEMBER PROCEDURE add_verlosung(in_verlosung WP.TYPE_VERLOSUNG) , MEMBER PROCEDURE add_ohc(in_ohc WP.TYPE_GATTUNG_OHC) , MEMBER PROCEDURE add_termin(in_termin WP.TYPE_GATTUNG_TERMIN) , MEMBER PROCEDURE add_opposition(in_opposition WP.TYPE_OPPOSITION) , MEMBER PROCEDURE INIT_KAPITAL_DETAIL(SELF IN OUT TYPE_GATTUNG) , MEMBER FUNCTION  GET_KAPITAL_DETAIL(SELF IN OUT TYPE_GATTUNG) RETURN WP.TABLE_KAPITAL , MEMBER PROCEDURE INIT_FID_DETAIL(SELF IN OUT TYPE_GATTUNG) , MEMBER FUNCTION  GET_FID_DETAIL(SELF IN OUT TYPE_GATTUNG) RETURN WP.TABLE_WMFID , MEMBER PROCEDURE INIT_SCD_FIDS(IN_DATUM DATE DEFAULT NULL) , MEMBER PROCEDURE INIT_OHC(IN_BOERSENPLATZ_ID VARCHAR2) ,… ) NOT FINAL

17 Schwergewichtiger TYPE (Fortsetzung)
CREATE OR REPLACE TYPE TABLE_ERTRAG AS TABLE OF WP.TYPE_ERTRAG; CREATE OR REPLACE TYPE TYPE_ERTRAG UNDER WP.ROW_ERTRAG_BASE (   -- Attributes   id               NUMBER(12) , fids             WP.TABLE_WMFID   -- Methods , CONSTRUCTOR       FUNCTION  TYPE_ERTRAG RETURN SELF AS RESULT , CONSTRUCTOR       FUNCTION  TYPE_ERTRAG(in_wmdaten WP.TYPE_WMDATEN) RETURN SELF AS RESULT , CONSTRUCTOR       FUNCTION  TYPE_ERTRAG(OBJECT_TYPE_NAME VARCHAR2, ID NUMBER, BID_NR VARCHAR2, DATUM DATE, FIDS WP.TABLE_WMFID) RETURN SELF AS RESULT , CONSTRUCTOR       FUNCTION  TYPE_ERTRAG(BID_NR VARCHAR2, DATUM DATE, FIDs WP.TABLE_WMFID) RETURN SELF AS RESULT , CONSTRUCTOR       FUNCTION  TYPE_ERTRAG(in_BID_NR VARCHAR2, in_DATUM VARCHAR2, in_FIDs WP.TABLE_WMFID) RETURN SELF AS RESULT , CONSTRUCTOR       FUNCTION  TYPE_ERTRAG(IN_ERTRAG_BASE_ID NUMBER, IN_DATUM DATE DEFAULT NULL) RETURN SELF AS RESULT , MEMBER            PROCEDURE INIT_SCD_FIDS(IN_DATUM DATE DEFAULT NULL) , OVERRIDING MEMBER FUNCTION  compare(in_type1 GLOBAL.TYPE_OBJECT, in_type2 GLOBAL.TYPE_OBJECT) RETURN INTEGER , MEMBER            PROCEDURE getDBid(in_gattung_id NUMBER) , MEMBER            PROCEDURE save(in_gattung_id NUMBER,IN_DATUM DATE DEFAULT SYSDATE) , MEMBER            FUNCTION  TO_VF1 RETURN GLOBAL.TABLE_VARCHAR2 ) NOT FINAL CREATE OR REPLACE TYPE ROW_ERTRAG_BASE UNDER GLOBAL.TYPE_OBJECT (-- attributes     ERTRAG_BASE_ID     NUMBER(12)   , GATTUNG_BASE_ID    NUMBER(12)   , BID_NR             VARCHAR2(5)   , DATUM              DATE   , ERSTELLT_ZST       DATE   , GEAENDERT_ZST      DATE   , ERSTELLT_ID        NUMBER(12)   , GEAENDERT_ID       NUMBER(12)   , ERSTELLT_IP        VARCHAR2(30)   , GEAENDERT_IP       VARCHAR2(30)   , GEAENDERT_ZAEHLER  NUMBER(10)   -- define constructors   , CONSTRUCTOR FUNCTION ROW_ERTRAG_BASE RETURN SELF AS RESULT   , CONSTRUCTOR FUNCTION ROW_ERTRAG_BASE(ERTRAG_BASE_ID NUMBER, GATTUNG_BASE_ID NUMBER, BID_NR , … ) NOT FINAL

18 Schwergewichtiger TYPE & Load Balancing
MEMBER PROCEDURE INIT_KAPITAL_DETAIL(SELF IN OUT TYPE_GATTUNG)   IS     methodenname  CONSTANT VARCHAR2(300) := 'WP.'||$$PLSQL_UNIT||'.INIT_KAPITAL_DETAIL';     FUNCTION parm RETURN VARCHAR2 IS BEGIN       RETURN substr( 'Parameter: ' || CHR(10) || 'SELF:' || SELF.TO_STRING(),1,32760);     END;   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, parm());     END IF;     SELF.kapitals := WP.TABLE_KAPITAL();     FOR rec IN (SELECT d.kapital_base_id                   FROM WP.Kapital_Base d                  WHERE d.gattung_base_id = SELF.id                  ORDER BY datum                )     LOOP       SELF.kapitals.EXTEND;       SELF.kapitals(SELF.kapitals.LAST) :=         WP.TYPE_KAPITAL(in_kapital_base_id => rec.kapital_base_id);     END LOOP;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.pa_trace.TRACE( GLOBAL.pa_trace.TRACE_ERROR, methodenname, parm()||CHR(10)||         ', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;     MEMBER FUNCTION  GET_KAPITAL_DETAIL(SELF IN OUT TYPE_GATTUNG) RETURN WP.TABLE_KAPITAL   IS     methodenname  CONSTANT VARCHAR2(300) := 'WP.'||$$PLSQL_UNIT||'.GET_KAPITAL_DETAIL';     FUNCTION parm RETURN VARCHAR2 IS BEGIN       RETURN substr('Parameter: ' || CHR(10) || 'SELF:' || SELF.TO_STRING(),1,32760);     END;   BEGIN     IF SYS_CONTEXT('TRACE','TRACE_LEVEL') >= GLOBAL.PA_TRACE.TRACE_TRACE THEN       GLOBAL.PA_TRACE.TRACE( GLOBAL.PA_TRACE.TRACE_TRACE, methodenname, parm());     END IF; IF SELF.kapitals IS NULL THEN     SELF.INIT_KAPITAL_DETAIL(); END IF;     RETURN SELF.kapitals;   EXCEPTION     WHEN OTHERS THEN       GLOBAL.pa_trace.TRACE( GLOBAL.pa_trace.TRACE_ERROR, methodenname, parm()||CHR(10)||         ', SQLcode=' || to_char(SQLCODE) || ', ' || SQLERRM);     RAISE;   END;

19 Fliegengewichtiger COMP
CREATE OR REPLACE TYPE COMP_GATTUNG UNDER GLOBAL.TYPE_OBJECT (   -- Attributes   GATTUNG_BASE_ID      NUMBER , WKN                  CHAR(6) , ISIN                 CHAR(12) , SH                   NUMBER(2) , NAME                VARCHAR2(80) , INSTRUMENT   VARCHAR2(80) , GELOESCHT    DATE   -- Methods , CONSTRUCTOR FUNCTION  COMP_GATTUNG RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION  COMP_GATTUNG(IN_GATTUNG_BASE_ID NUMBER) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION  COMP_GATTUNG(IN_ISIN VARCHAR2, IN_SH NUMBER DEFAULT 0) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION  COMP_GATTUNG(IN_WKN VARCHAR2,  IN_SH NUMBER DEFAULT 0) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION  COMP_GATTUNG(IN_ISIN VARCHAR2, IN_WKN VARCHAR2, IN_SH NUMBER) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION  COMP_GATTUNG(IN_SECURITY_ID VARCHAR2, IN_ID_SOURCE VARCHAR2) RETURN SELF AS RESULT , MEMBER FUNCTION GET_ABRECHNUNGS_WAEHRUNG_ISO(IN_BOERSENPLATZ_ID VARCHAR2) RETURN VARCHAR2 , MEMBER FUNCTION GET_ABRECHNUNGS_WAEHRUNG_ID(IN_BOERSENPLATZ_ID VARCHAR2) RETURN NUMBER , MEMBER FUNCTION GET_ABRECHNUNGS_WAEHRUNG_ISO RETURN VARCHAR2 , MEMBER FUNCTION GET_HANDELS_WAEHRUNG_ISO(IN_BOERSENPLATZ_ID VARCHAR2) RETURN VARCHAR2 , MEMBER FUNCTION GET_HANDELS_WAEHRUNGEN_ISO(IN_BOERSENPLATZ_ID VARCHAR2) RETURN BBS.TAB_ROW_WAEHRUNG , MEMBER FUNCTION GET_RIC RETURN VARCHAR2 , MEMBER FUNCTION GET_RIC(IN_BOERSENPLATZ_ID VARCHAR2) RETURN VARCHAR2 , MEMBER FUNCTION GET_SEDOL RETURN VARCHAR2 , MEMBER FUNCTION GET_CUSIP RETURN VARCHAR2 , MEMBER FUNCTION GET_EMITTENT_NR RETURN VARCHAR2 , MEMBER FUNCTION GET_HEIMATLAND_ISO RETURN VARCHAR2 , MEMBER FUNCTION GET_HEIMATBOERSE_ID RETURN VARCHAR2 , MEMBER FUNCTION GET_LETZTER_HANDELSTAG(IN_BOERSENPLATZ_ID VARCHAR2) RETURN DATE , MEMBER FUNCTION IS_MIFID_RELEVANT RETURN BOOLEAN , MEMBER FUNCTION IS_DAX RETURN BOOLEAN , MEMBER FUNCTION IS_MDAX RETURN BOOLEAN , MEMBER FUNCTION IS_SDAX RETURN BOOLEAN , MEMBER FUNCTION IS_TECDAX RETURN BOOLEAN , MEMBER FUNCTION IS_STOXX RETURN BOOLEAN , MEMBER FUNCTION IS_HANDELBAR(IN_LAND_ISO VARCHAR2) RETURN BOOLEAN , MEMBER FUNCTION IS_HANDELBAR(IN_BOERSENPLATZ_ID VARCHAR2) RETURN BOOLEAN , MEMBER FUNCTION IS_HANDELBAR_FH(IN_BOERSENPLATZ_ID VARCHAR2) RETURN BOOLEAN , MEMBER FUNCTION IS_INVESTRO RETURN BOOLEAN , MEMBER FUNCTION IS_ZERTIFIKAT RETURN BOOLEAN , MEMBER FUNCTION IS_WARRANT RETURN BOOLEAN , MEMBER FUNCTION IS_FOND RETURN BOOLEAN , MEMBER FUNCTION IS_BEGO_FOND RETURN BOOLEAN , MEMBER FUNCTION IS_EHF RETURN BOOLEAN , MEMBER FUNCTION IS_DEF RETURN BOOLEAN , … ) NOT FINAL

20 Schwergewichtiger TYPE
CREATE OR REPLACE TYPE TYPE_KUNDE UNDER BBS.ROW_KUNDE (  -- attributes   DEPOT               BBS.TABLE_DEPOT,   KONTEN             BBS.TABLE_KONTO,   KONTEN_BBS     BBS.TABLE_KONTO_BBS,   land                VARCHAR2(35),   nationalitaet       VARCHAR2(35),   rechtsform          VARCHAR2(105),   branche             VARCHAR2(105),   betreuer1           VARCHAR2(35),   betreuer2           VARCHAR2(35),   betreuer3           VARCHAR2(35),   betreuer4           VARCHAR2(35),   stammkreis          VARCHAR2(35)   -- define constructors   , CONSTRUCTOR FUNCTION TYPE_KUNDE       RETURN SELF AS RESULT   , CONSTRUCTOR FUNCTION TYPE_KUNDE(IN_STAMMNR VARCHAR2)       RETURN SELF AS RESULT   , CONSTRUCTOR FUNCTION TYPE_KUNDE(IN_UNTERDEPOTID NUMBER)       RETURN SELF AS RESULT   , CONSTRUCTOR FUNCTION TYPE_KUNDE(IN_KUNDENID NUMBER, IN_KONTOID NUMBER)       RETURN SELF AS RESULT   , CONSTRUCTOR FUNCTION TYPE_KUNDE(IN_DEPOTNUMMER CHAR, IN_REFERENZNUMMER NUMBER)       RETURN SELF AS RESULT     -- static functions instead of constructors   -- duplicate signature problem in Java   , STATIC FUNCTION CONSTRUCTOR_TYPE_KUNDE(IN_KUNDENID NUMBER)       RETURN BBS.TYPE_KUNDE   , STATIC FUNCTION CONSTRUCTOR_KONTONUMMER(IN_KONTONUMMER VARCHAR2)       RETURN BBS.TYPE_KUNDE   , STATIC FUNCTION CONSTRUCTOR_KONTO_BBS_ID(IN_KONTO_BBS_ID NUMBER)       RETURN BBS.TYPE_KUNDE   -- define member functions   , MEMBER PROCEDURE ROW_SELECT(IN_STAMMNR VARCHAR2)   , MEMBER PROCEDURE ROW_SELECT(IN_KUNDENID NUMBER, IN_VERSION NUMBER)   , MEMBER PROCEDURE init_text_fields   , MEMBER PROCEDURE INIT_DEPOT(SELF IN OUT TYPE_KUNDE,                           IN_REFERENZNUMMER NUMBER DEFAULT NULL)   , MEMBER PROCEDURE INIT_DEPOT(SELF IN OUT TYPE_KUNDE, IN_DISPLAY_ID     NUMBER, IN_REFERENZNUMMER NUMBER DEFAULT NULL)   , MEMBER PROCEDURE INIT_KONTEN(SELF IN OUT TYPE_KUNDE) , … ) NOT FINAL

21 Fliegengewichtiger COMP
CREATE OR REPLACE TYPE COMP_KUNDE UNDER GLOBAL.TYPE_OBJECT (   -- Attributes   KUNDE_ID             NUMBER(12) , STAMMNUMMER          CHAR(10) , INHABER              VARCHAR2(35) , SPRACHE_ID           NUMBER(12)   -- Methods , CONSTRUCTOR FUNCTION COMP_KUNDE RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION COMP_KUNDE(in_kunde_id NUMBER) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION COMP_KUNDE(in_stammnummer CHAR) RETURN SELF AS RESULT , CONSTRUCTOR FUNCTION COMP_KUNDE(in_unterdepot_id NUMBER) RETURN SELF AS RESULT ) NOT FINAL

22 Mischung OO-Type und relationale FK ID
Analogon zur DEREF in ODBMS kann man mit dem FK eines Type den anderen Type instanzieren declare b wph.ROW_BOERSE; h wph.ROW_HANDELSSYSTEM; begin b := wph.ROW_BOERSE('194'); h := wph.ROW_HANDELSSYSTEM(b.HANDELSSYSTEM_ID); end;

23 Wie programmieren wir in PL/SQL
-- Allocation ermitteln FOR rec_alloc IN (SELECT g.COLUMN_VALUE AS xml FROM TABLE (XMLSEQUENCE(rec_order.XML.EXTRACT('Order/Allocations/Allocation'))) g) LOOP -- Neue Allocation anlegen t_allocation := NEW WPH.TYPE_ALLOCATION ( IN_KUNDE_ID => t_ob.KUNDE_ID , IN_ANNAHMEART_ID => t_ob.ANNAHMEART_ID , IN_ALLOC_IDENT => t_ob.ORDER_NR_EXTERN , ...); -- Order hinzufuegen t_allocation.ADD_ORDER(IN_ORDER_BUCH_ID => t_ob.ORDER_BUCH_ID); -- Client Account ermitteln v_client_account := GLOBAL.PA_XML.EXTRACT_STRING(rec_alloc.XML, 'Allocation/ClientAccount'); -- Stueckzahl ermitteln v_stueckzahl := GLOBAL.PA_XML.EXTRACT_NUMBER(rec_alloc.XML, 'Allocation/Stueckzahl'); IF v_stueckzahl IS NOT NULL THEN -- Allocation hinzufuegen t_allocation.ADD_ALLOCATION(IN_CLIENT_ACCOUNT => v_client_account , IN_STUECKZAHL => GLOBAL.PA_XML.EXTRACT_NUMBER(rec_alloc.XML, 'Allocation/Stueckzahl') , IN_KURS => NULL); ELSE -- Prozentsatz ermitteln v_prozentsatz := GLOBAL.PA_XML.EXTRACT_NUMBER(rec_alloc.XML, 'Allocation/Prozentsatz'); , IN_PROZENTSATZ => v_prozentsatz); END IF; END LOOP; -- Allocation einstellen t_allocation.EINSTELLEN();

24 Wie programmieren wir in PL/SQL
-- zentrale Schnittstelle zum Steuermodul PROCEDURE STEUER_BERECHNUNG(...) IS t_steuer BBS.TYPE_STEUER; BEGIN -- geschäftsbedingt Instanzierung IF ....GESCHAEFTSART = 'KKZ' THEN t_steuer := NEW BBS.TYPE_STEUER_KKZ(...) ELSIF ....GESCHAEFTSART = 'WPK' THEN t_steuer := NEW BBS.TYPE_STEUER_WPK(...) ELSIF <weitere Geschäftsbereiche> THEN t_steuer := NEW BBS.TYPE_STEUER_XXX(...) END IF; -- Aufruf der Steuerverrechnung t_steuer.BERECHNE_STEUERN; END;

25 Unsere Leitsätze Man sollte alles so einfach wie möglich machen, aber nicht einfacher Albert Einstein "Der einfache und klare Zweck sowie Prinzipien bedingen komplexes und intelligentes Verhalten". "Komplexe Regeln und Vorschriften bedingen einfaches und dummes Verhalten". Dee Hock, Designer VISA-Systems Ein System erreicht Perfektion nicht, wenn nichts weiter hinzugefügt werden kann, sondern wenn nichts weiter entfernt werden kann. ???

26 E-Mail : andriy.terletskyy@berenberg.de
Q&A Vielen Dank !
